4x4 4K UHD HDMI 2.0 Matrix Switcher with Audio De-embedding/Independent Routing (4K60-4:4:4 and HDR Support)

With four HDMI 2.0 inputs and four HDMI 2.0 outputs, the BG-4K-44MA 4K HDMI matrix switch allows users to share up to four HDMI sources with up to four displays. Perfect for when you need to change multiple sources to show on various displays or even select just one source to show on all displays with the press of a button. Audio can also be independently routed. Professional-grade picture and audio quality are achieved with support for 4K resolutions and various high-quality audio formats. Connectivity and Quality: The BG-4K-44MA supports high resolutions up to 4K@60Hz 4:4:4 with HDR. With 18 Gbps of uncompressed bandwidth, HDMI signals are routed with no loss of quality. All HDMI ports on this matrix are HDCP 2.2 compliant. This device is also equipped with auto-downscaling on all outputs, ensuring compatibility with legacy displays. The BG-4K-44MA also supports Digital S/PDIF and Balanced audio output formats. The BG-4K-44MA offers multiple operating methods including TCP/IP (Web GUI). The full-featured web interface and managing software enables users to adjust advanced settings such as EDID management, mapping, and network settings. Audio Matrixing: This unit features advanced audio matrixing capabilities. Audio can be independently routed separately from the video signals. This feature provides flexible audio management options for a variety of installation scenarios.

• HDCP Compliant - HDMI 2.0 (18Gbps) HDCP 2.2 (and all earlier versions supported).
• 4K@60Hz - Up to 4K@60Hz 4:4:4 with HDR. Supports downscaling to 1080p.
• Operating Options - via front panel, TCP/IP (Web GUI).
• HDR Pass-through - HDR10, HDR10+ pass-through supported.
• Audio Matrixing - The audio can be independently routed. Auto Scaling - Downscaling on all outputs.
